Triumph is engineered for superior accuracy and performance in even the toughest target materials, and every size Triumph is designed at the maximum allowable diameter for World Archery competition.
With a choice of four sizes, three nock systems, and five-point weights, there’s a Triumph for every competitive bow style and required state of tune.
Triumph’s internal armour system provides a natural advantage in terms of front-of-centre balance, providing even more stability and accuracy, without compromising the dynamic spine.
STOCK LENGTHS:
- 350 Spine - 31.25"
- 400 Spine - 31.25"
- 450 Spine - 30.25"
- 500 Spine - 30.25"
FEATURES:
- Armoured Carbon Technology
- Straightness: ± .002
- Weight tolerance: ± 1 grain
- All sizes at World Archery maximum allowed 9.3mm outside diameter
- Black, smooth matte finish
- Multi-layer wrapped carbon fibres
- Pin nock adapter sold separately
- Points fit all shaft sizes, sold separately, available weights: 100, 125, 150, 175 and 200 grains
- Nominal GPI: 350/9.25, 400/8.8, 450/8.5, 500/8.2
Note: Triumph shafts are precision-cut and squared at the front for optimal point alignment and fit, and should only be cut from the rear before nock system installation and assembly. Cutting the shaft at the point end will reduce the effectiveness of the internal armour system and potentially decrease durability in hard targets. This will void the warranty.
Cutting Instructions: Use only a high-speed, thin-blade pro shop saw for cutting Triumph shafts. NOTE: Cut shafts ONLY from the rear, designated by the printed gold band. DO NOT cut the end with the aluminium armour core.
Point installation: Triumph shafts are compatible with the use of Easton low-temperature hot melt cement for point installation. Easton recommends the use of a gel-type cyanoacrylate for UNI bushing installation and a small drop of hot melt for installation of pin nock adapters.
