Mybo Edge Compound Bow
The 2018 Mybo Edge continues our commitment to producing world class compound bows.
Drawing on a depth of knowledge and first hand experience from world class archers, combined with decades of compound bow manufacturing expertise, the Edge brings together those subtle qualities required to give you the edge you need.
Packed with features, including our next generation ergonomic grip, straight and level nocking point travel, 7075 alloy riser, optimised modular cam system, Limb tuner block and many more accuracy boosting details.
Available in a 38.5” length as standard, or a custom build 35” model for draw lengths down to 23.5".
• Made in the UK
• Riser machined from a solid billet of 7075 aluminium
• Pockets and cams all fully machined
• Polished annodised finish
• Next generation ergonomic grip
• Stainless steel sealed ball bearings
• Oversized 6mm axles for increased rigidity
• Balanced, centreline cam design
• Totally customizable draw stop and back end feel
• Totally straight and level nocking point travel through every draw length setting
• Wide stance, load balanced limbs with high pre-load
• Adjustable cable guard with powerful clamping mechanism
• AAE Slippery Slide as standard
• SVL limb dampers as standard
• Stainless steel stabiliser inserts and rear mounting bushings bushings
• Personalised flag decal of choice
• Axle to Axle: 38.5"
• Brace Height: 7.5"
• Mass Weight: 4.9lbs
• ATA Speed: 318fps
• Cam 1: 29" - 32" (replaceable modules in 1/2" increments)
• Cam 2: 25" - 30" (replaceable modules in 1/2" increments)
• Let off: 65% - 80%
• Max draw weights - Standard: 40#, 50#, 60#
CUSTOM BUILD 35" OPTION IS AVAILABLE DOWN TO 23.5". Please enquire for details.
*Specifications are approximate depending on configuration
* Draw weights listed are the maximum when fully wound up. Limbs can be backed out a maximum of 7 full turns, The amount of poundage change varies depending on the original peak weight. Typically this equates to approximately 17%.
Great top end compound bow
Very nice bow, rock solid feel throughout shot. Very neutral in hand without stabiliser and the way the cams are set up, none of this yoke tuning business, so very easy to tune. Doesnt have a shot absorbed rubber or string stop, but this is deliberate, ask them why? Yes it is pricey but everything is well build so worth it. Also the guys in Merlin are very happy to help rectify any issues with the bow and actually give pointers on shooting better(thanks Ben!) The bow is made at Merlin, so if you go down, you could have one set up the same day, and none of this order in and wait 8 weeks business. It would be nice if there were more colour choices but what they have is sharp and bright. Buy it and enjoy!!
Fantastic Bow Merlin do it again
I upgraded from a Origin to an Edge, I enjoyed the Origin but I had certain small issues with it. The Edge fixed all these little issues it is such a stable forgiving bow rock solid in anytthing but strong winds with minimum stabiliser weights, its new cams produce such a smooth draw and let down cycle its hard to find where the let off kicks in. A fantastic big brother to the Origin and a great bow at a much more friendly price the equiliventst from the likes of Matthews, PSE and Hoyt
A nice forgiving bow.
Hi guys, just an update I shot at the SFAA championships at the weekend shot the Edge still on CMFS (finger release) took the Gold medal. What a lovely forgiving bow. If I could improve it I would ask for a longer axle to axle length, still it does the job. Thanks...
Very nice bow
Been shooting the Edge for a couple of months now and its lovely and easy to shoot. I own 10 different bows from hoyt, mathews, prime, bowtech, and this is now my favorite bow. Very well build quality and well designed. I higly recomend this bow.
Well done Ben and Team for producing an amazing bow.
Hi Folks I have had my Edge for just over a week and decided to use it (instead of my Hoyt) at the STAFAA indoor championship I got Gold! What a fantastic bow so forgiving so easy to shoot I shot it CMFS limited (fingers) I had a Max 2000 for 16 years and regretted selling it but now happy to be back in the Merlin Fold!
Having owned a Merlin Max 2000 some years ago, I was drawn to the Mybo Origin, which I absolutely love, so couldn't resist the temptation of the brilliant new Mybo Edge. Yet another no-gimmick well designed & engineered bow from Ben. Have broken some state & a national record in my category here in Australia with these superb bows. Can't imagine where to next for Mybo after these beauties. Wouldn't change a thing.
Best of British..MYBO Edge
I had heard a lot of talk about a new bow being launched by Merlin, knowing how well the Origin had been received and seeing many on the courses, I was very interested to see what Ben and the team had been working on. It was perfect timing, I was after a more target orientated bow and the 38.5” ATA of the new Mybo Edge sounded spot on. After a demo shoot with the Mybo Edge in early August, I was pretty impressed, the draw cycle was silky smooth, it felt balanced and held steady even with no front stabiliser. On release the bow was sharp, it felt fast for a target bow with these specs. I promptly order an Edge in Orange Blaze.
I collected a few weeks later, the orange anodizing looked amazing, highlighting the detailing and design in the riser. James helped my transfer my bits and set up the bow, from the first arrow, this bow was better than I remembered from August! Solid and stable, the feedback from the bow was something new to me, I was used to shooting a very dead in the hand bow, the MYBO Edge gives back. The tuning capabilities of the Edge are too long to list, straight out of the box this bow performed. I would seriously recommend anyone in the market for a new target bow to pop to Merlin and try a MYBO Edge, this British born bow will make waves (across the Atlantic!). The Team at Merlin: James, Luke, Dan, Jim and Ben Jones, provide top class customer service, big thanks to you all for making a stunning bow. 5 Stars all round.
Another hit from Mybo.
I’ve been fortunate enough this year to have shot the Mybo Origin and three top end PSE Compounds. Having stupidly sold the Origin which in my opinion was superior to the other three, it left me no choice but to sell everything and head back to Mybo. After watching Ben’s brilliant video review a few times, I needed no more convincing and promptly ordered up my beautiful Edge in midnight black. As the other reviews say, this is one fantastic bow to shoot. Holds on target great, draw cycle fantastic and the 60lbs feels like nothing at all to pull. Only thing left to say is, Sssshhhh!! don’t want to tell too many people how good this bow is or everyone will be shooting one!
Ps, huge thanks to Ben and the team for the free repairs after my little accident
Collected my Edge in August. What a fantastic improvement to my Origin. Has improved My groups at all ranges, is more stable and I find it more forgiving am able to hold it longer in the aim.
Just an all round fantastic bit of engineering. Merlin at Loughborough gave me excellent service as is the norm.
Fantastic bow and customer service.
Called in at Merlin Loughborough yesterday to pick up my Mybo Edge, and wow. I have the cherry red and when it first came out it looked the business. This bow is visually very impressive. Big thanks to Dan and Ben for their help getting all the stuff transferred over from my Bowtech Specialist,and also their help setting up the Edge. Straight off the bat the bow has a really smooth draw cycle and and is very comfortable in the hand. The bow is also very quiet on the shot too. During set up and paper tuning I must have shot around 60-80 arrows so can only review it on initial shooting and set up, but I feel this bow is going to be very popular. With it having two available axle lengths, a good range of colours and be as adjustable as this bow is then you need to get yourself into a Merlin store and try one if you are considering a new bow. So ok, I only shot 60-80 arrows and given it 4 stars, but this could easily get the full 5 stars once I have done some more shooting. Thanks Merlin, another quality product.
MYBO EDGE - Great bow & great service!
Collected my MYBO EDGE from Merlin Loughborough. Fitted the accessories on the bow with great help from store staff. Then it was time to shoot the bow and after shooting the first arrow all I can say is WOW!!! The way this bow shoots is incredible. I never have had such a positive feeling from shooting a bow for the first time. You can feel all the energy is transformed into shooting the arrow out of the bow. It feels very solid and stable to shoot and looks great as well. I like the open design of the riser, which has been able due to the use of 7075 aluminium which makes it very strong. Ben and his team have done another great job at designing & making another great compound bow in the MYBO line up. It's also nice to know it is British made in house at Merlin Loughborough. If you are looking at a top line compound bow, make sure you put the MYBO EDGE on your list for trying out, you'll not be disappointed.
